Basic XDP

A lightweight XDP/eBPF firewall for automatic port whitelisting and basic DDoS protection on Linux hosts.

Although there are some XDP firewall solutions available, Basic XDP provides users with automatic port whitelisting, which makes maintenance easier.

⚠️ XDP only filters traffic that reaches your NIC. If your upstream bandwidth is already saturated by a volumetric attack, this tool cannot help. For large-scale DDoS mitigation, consider upstream scrubbing services or a DDoS-protected hosting provider.

Overview

What is XDP?

XDP (eXpress Data Path) is an eBPF-based, high-performance packet processing path that runs before packets enter the Linux networking stack (at the NIC driver level). This makes it significantly faster than traditional iptables/nftables filtering.

Why Basic XDP?

Personal cloud instances are constantly scanned and probed. Traditional firewalls like iptables work, but they process packets after the kernel networking stack — adding latency and CPU overhead.

Basic XDP hooks in at the NIC driver level, before any kernel processing. And unlike other XDP solutions, it manages the port whitelist for you: a daemon watches which ports are actually open on your system and keeps the active backend in sync automatically. When a host cannot run XDP, it can fall back to an nftables ruleset instead of failing outright.

How It Works

Incoming Packet
      │
      ▼
┌─────────────┐
│  NIC Driver │  ← XDP hooks here (before kernel stack)
└──────┬──────┘
       │
       ▼
┌──────────────────────────────┐
│       xdp_port_whitelist     │
│                              │
│  ETH → IPv4/IPv6 → TCP/UDP   │
│                              │
│  IPv4 TCP SYN? → whitelist + │
│                  conntrack   │
│  IPv4 TCP ACK? → conntrack   │
│  IPv4 UDP?     → ct/port/IP  │
│  ICMP/ARP? → PASS            │
│                              │
│  Not in whitelist → DROP     │
└──────────────────────────────┘
       │
       ▼
  XDP_PASS / XDP_DROP

Components

1. xdp_firewall.c — eBPF/XDP kernel program that filters packets at wire speed
2. tc_flow_track.c — eBPF tc egress helper that records outbound IPv4/IPv6 TCP SYN packets and UDP reply tuples
3. xdp_port_sync.py — userspace daemon that syncs TCP/UDP listening ports and trusted IPv4 source IPs
4. bxdp — operator CLI for statistics, sync, service control, and daemon log level
5. setup_xdp.sh — installer that compiles the BPF objects, installs the runtime launcher, and sets up boot-time auto-sync

Key Features

• Wire-speed filtering via XDP (bypasses kernel network stack)
• ~40–65 ns per-packet latency measured on real hardware (see Benchmarks)
• Auto-sync whitelist: daemon watches listening sockets and updates the active backend in real time
• IPv4 + IPv6 TCP conntrack hardening: pure SYN creates temporary state; unsolicited ACK packets are dropped
• Kernel-side outbound state tracking: a tc egress program records host-initiated IPv4/IPv6 TCP SYN packets and UDP reply tuples so return traffic can be matched at XDP without reopening the old bypasses
• IPv4 UDP hardening: inbound server ports use udp_whitelist, reply traffic can be matched by udp_conntrack, and explicitly trusted IPv4 sources can still be allowed via trusted_src_ips
• IPv6 UDP stateful filtering: reply traffic uses the shared udp_conntrack, and inbound server traffic still uses udp_whitelist (note: trusted_src_ips is currently IPv4-only)
• IPv6 support, including extension header traversal on both XDP and tc egress, plus explicit non-initial fragment drops
• Periodic conntrack sync (seeding established flows): the daemon now periodically seeds existing IPv4/IPv6 TCP sessions into tcp_conntrack, which helps preserve active sessions after re-attaching XDP or manual map clears.
• Reload-safe XDP attach: the installer also pre-seeds existing sessions before initial attach.
• Pinned BPF maps that survive reloads and can be updated at runtime
• ICMP/ICMPv6/ARP passthrough (ping + IPv6 NDP still work)
• Boot-time loader: restores protection on reboot instead of only syncing userspace state
• Systemd + OpenRC support: installs the service automatically when either init system is present
• Configurable daemon verbosity: bxdp log-level debug|info|warning|error updates the installed service config and restarts it
• Native + generic XDP: tries native first, then generic
• nftables fallback: if both XDP attach modes fail, keeps automatic port whitelisting with a dynamic nftables ruleset

Requirements

• Linux kernel ≥ 4.18 for the XDP backend
• Popular Linux distro with a supported package manager: Debian/Ubuntu, Fedora/RHEL, openSUSE, Arch, or Alpine
• Root (sudo) privileges
• nftables support is used automatically as the compatibility fallback when XDP cannot be attached

Dependencies (auto-installed)

• clang, llvm — compile BPF
• libbpf or libbpf-dev / libbpf-devel — BPF headers, depending on distro
• bpftool — manage BPF maps
• iproute2 or iproute — provides both ip and tc for XDP attach and UDP egress tracking
• python3 — sync daemon runtime
• nftables — compatibility fallback backend

Quick Start

curl -fsSL https://raw.githubusercontent.com/Kookiejarz/basic_xdp/refs/heads/main/setup_xdp.sh | sudo bash

Install a Specific Release

curl -fsSL https://raw.githubusercontent.com/Kookiejarz/basic_xdp/refs/tags/v26.4.7a/setup_xdp.sh | sudo bash

Using a tag gives you a reproducible installer version instead of tracking the latest main branch.

When the installer is executed from stdin (curl | bash), it prefers the matching GitHub source files instead of stale local files from the current working directory.

Automated Distro Checks

The repository includes a GitHub Actions matrix that installs basic runtime tools in supported Linux container images and runs a non-destructive setup_xdp.sh --dry-run smoke test.

The installer reads /etc/os-release to classify the distro family before choosing the matching package-manager and dependency set.

You can also run the non-destructive smoke test locally:

bash setup_xdp.sh --dry-run

If you only want the package-manager and init-system probe, use:

bash setup_xdp.sh --check-env

Install From Source

git clone https://github.com/Kookiejarz/basic_xdp.git
cd basic_xdp

# Auto-detect interface
sudo bash setup_xdp.sh

# Or specify interface
sudo bash setup_xdp.sh eth0

# Compare local files with GitHub first, then decide interactively
sudo bash setup_xdp.sh --check-update

# Non-interactive mode for CI / automation
sudo bash setup_xdp.sh --check-update --force

What setup_xdp.sh Does (Step-by-Step)

1. Checks for root privileges
2. Auto-detects default network interface
3. Installs missing dependencies via the detected package manager
4. Uses local xdp_firewall.c / tc_flow_track.c / xdp_port_sync.py / bxdp by default from a local checkout; when run from stdin, it prefers the matching GitHub copies
5. Compiles the XDP and tc BPF objects when the host has the required toolchain
6. Pre-seeds current IPv4/IPv6 established TCP sessions into tcp_conntrack before attaching XDP
7. Loads and attaches a tc clsact egress program that records outbound TCP SYN and UDP reply tuples
8. Tries to attach XDP in native mode, then generic mode
9. Falls back to nftables automatically if XDP cannot be attached
10. Installs the runtime launcher at /usr/local/bin/basic_xdp_start.sh
11. Installs the sync daemon at /usr/local/bin/xdp_port_sync.py
12. Runs an initial port sync using the selected backend
13. Registers and starts xdp-port-sync on systemd or OpenRC when available

BPF Maps

Pinned directory: /sys/fs/bpf/xdp_fw/

Manually Add / Remove a Port

# Allow TCP port 8080
bpftool map update pinned /sys/fs/bpf/xdp_fw/tcp_whitelist \
    key 0x90 0x1f 0x00 0x00 value 0x01 0x00 0x00 0x00

# Remove TCP port 8080
bpftool map delete pinned /sys/fs/bpf/xdp_fw/tcp_whitelist \
    key 0x90 0x1f 0x00 0x00

# View current TCP whitelist
bpftool map dump pinned /sys/fs/bpf/xdp_fw/tcp_whitelist

Key encoding note: the map type is now ARRAY (BPF_MAP_TYPE_ARRAY), so the key is a 4-byte little-endian __u32 port number (host byte order). Example: 8080 = 0x00001F90 → bytes 0x90 0x1f 0x00 0x00

Why ARRAY instead of HASH?

Originally, this project used BPF_MAP_TYPE_HASH for the whitelist. We transitioned to BPF_MAP_TYPE_ARRAY for several critical reasons:

• O(1) Lookup Time: An Array map provides constant-time lookup ($O(1)$) by directly indexing into memory using the port number. A Hash map averages O(1) but degrades under hash collisions, whereas an Array map guarantees O(1) by direct index access with no collision possible. :))))
• Zero Hash Collisions: With 65,536 entries (one for every possible port), there is no possibility of hash collisions. In a Hash map with a small max_entries (e.g., 64), collisions frequently occur during high-volume scans, causing latency spikes.
• CPU Cache Efficiency: Because the Array is a contiguous block of memory, the CPU's prefetcher can handle it much more efficiently than the pointer-chasing required by Hash map buckets.

Auto-Sync Daemon

The daemon xdp_port_sync.py runs behind the launcher /usr/local/bin/basic_xdp_start.sh and provides real-time updates for either backend:

1. Event-driven: Uses Linux Netlink Process Connector to detect exec() and exit() events immediately.
2. Efficient Discovery: Uses psutil to read /proc directly for listening ports (no slow ss or netstat subprocesses).
3. Safety Fallback: Performs a full sync every 30 seconds to ensure consistency.
4. Backend Sync: Updates either pinned BPF maps or nftables sets, depending on what the host supports.
5. UDP Discovery Rule: Because UDP has no LISTEN state, the daemon syncs unconnected bound UDP sockets (no remote peer) into udp_whitelist, which is a practical approximation of server-style UDP ports.
6. Trusted Source IPs: Optional IPv4 addresses can be synced into the XDP-side trusted_src_ips map for reply-style UDP traffic such as DNS or NTP.
7. Backend Guard Rails: In auto mode, the daemon only selects XDP when the required pinned maps are present; otherwise it falls back to nftables instead of crashing.

Outbound TCP/UDP reply tracking is kernel-side: a tc egress program records reverse reply tuples into tcp_conntrack and udp_conntrack, and the XDP ingress path checks those maps before falling back to tcp_whitelist, udp_whitelist, or trusted_src_ips.

Permanent Ports

Edit xdp_port_sync.py to always allow specific ports:

TCP_PERMANENT = {22: "SSH-fallback"}   # Optional: add ports you never want blocked
UDP_PERMANENT = {50000: "custom-udp-service"}  # Use this for real high-port UDP services
TRUSTED_SRC_IPS = {"1.1.1.1": "cloudflare-dns"}

If a real UDP server uses a high port, add it to UDP_PERMANENT explicitly so it remains whitelisted even when the daemon's socket heuristics cannot distinguish it cleanly from transient client traffic.

You can also add trusted IPv4 sources at runtime:

python3 /usr/local/bin/xdp_port_sync.py --backend auto --trusted-ip 1.1.1.1 cloudflare-dns
python3 /usr/local/bin/xdp_port_sync.py --backend auto --trusted-ip 129.6.15.28 ntp-nist --dry-run

--trusted-ip currently affects the XDP backend. The nftables fallback continues to use its own compatibility ruleset.

Daemon Management

# systemd
systemctl status xdp-port-sync
journalctl -u xdp-port-sync -f

# OpenRC
rc-service xdp-port-sync status

# Manual foreground run
/usr/local/bin/basic_xdp_start.sh

# One-shot sync with automatic backend selection
python3 /usr/local/bin/xdp_port_sync.py --backend auto
python3 /usr/local/bin/xdp_port_sync.py --backend auto --dry-run

# Increase foreground verbosity temporarily
python3 /usr/local/bin/xdp_port_sync.py --backend auto --log-level debug

Statistics

Basic XDP installs a convenience command /usr/local/bin/bxdp. Statistics are now built directly into bxdp, so you only need one operational command after installation.

# Single snapshot
sudo bxdp

# Real-time refresh
sudo bxdp watch

# Show delta rates (pps / bps)
sudo bxdp stats --rates

# Combine both
sudo bxdp stats --watch --rates --interval 2

# Run one manual sync
sudo bxdp sync

# View or change daemon log level
sudo bxdp log-level
sudo bxdp log-level debug

# Service control
sudo bxdp start
sudo bxdp stop
sudo bxdp restart
sudo bxdp status

What it shows:

1. xdp backend: per-category packet counters from /sys/fs/bpf/xdp_fw/pkt_counters, plus interface RX totals
2. nftables backend: current drop counter from the inet basic_xdp input chain, plus interface RX totals
3. --rates: packet deltas for XDP counters, and packet/bit deltas where byte counters are available

Counter labels in bxdp are intentionally human-readable:

1. TCP_NEW_ALLOW counts pure SYN packets admitted by tcp_whitelist
2. TCP_ESTABLISHED counts TCP packets admitted by tcp_conntrack
3. TCP_CT_MISS counts TCP ACK packets dropped because no conntrack entry existed
4. IPv6_ICMP covers ICMPv6, neighbor discovery, and other non-TCP/UDP IPv6 traffic that is passed through
5. ARP_NON_IP covers ARP and other non-IP Ethernet traffic

Post-Install Quick Commands

After installation, these are the main commands you will actually use:

# Help
sudo bxdp help

# Current statistics snapshot
sudo bxdp

# Live statistics
sudo bxdp watch

# Delta rates
sudo bxdp stats --rates

# Live delta rates
sudo bxdp stats --watch --rates --interval 2

# Run one manual sync
sudo bxdp sync

# Change daemon log verbosity and restart the service
sudo bxdp log-level
sudo bxdp log-level debug
sudo bxdp log-level info

# Service control
sudo bxdp start
sudo bxdp stop
sudo bxdp status
sudo bxdp restart

Source Update Check

When you run the installer from a cloned repo, local source files win by default. If you want the script to compare your local copies with GitHub first, use:

sudo bash setup_xdp.sh --check-update

In --check-update mode, the installer:

1. Downloads the GitHub version of xdp_firewall.c, tc_flow_track.c, xdp_port_sync.py, and bxdp to temporary files
2. Compares the local and GitHub SHA-256 hashes
3. Prompts you when they differ
4. Pulls the GitHub copy only if you confirm

Non-Interactive Mode

For CI or automated deployment, use:

sudo bash setup_xdp.sh --force

Or combine it with source comparison:

sudo bash setup_xdp.sh --check-update --force

In --force mode, the installer skips confirmation prompts and:

1. Pulls the GitHub copy automatically when --check-update finds a hash mismatch
2. Unloads any existing XDP program automatically before reinstalling

Packet Filtering Logic

TCP

• IPv4 + IPv6 stateful path:
  • If packet is a pure SYN and destination port is in tcp_whitelist → insert flow key into tcp_conntrack and PASS
  • If ACK is set and the flow key exists in tcp_conntrack → PASS
  • If ACK is set and no conntrack entry exists → count CNT_TCP_CT_MISS and DROP
  • Otherwise → DROP
• Kernel assist: a tc egress program records host-initiated IPv4/IPv6 TCP SYN packets immediately, closing the race where a very short outbound connection could receive SYN-ACK before conntrack state existed.
• Reload assist: setup_xdp.sh pre-seeds existing IPv4/IPv6 TCP sessions into tcp_conntrack before re-attaching XDP, which helps preserve active sessions during reinstall/restart.

UDP

• IPv4 stateful path:
  • If the inbound flow key exists in udp_conntrack → PASS
  • If destination port is in udp_whitelist → PASS
  • Else if source IPv4 address is in trusted_src_ips → PASS
  • Otherwise → DROP
• IPv6 stateful path:
  • If the inbound flow key exists in udp_conntrack → PASS
  • If destination port is in udp_whitelist → PASS
  • Otherwise → DROP
• Userspace assist: trusted IPv4 source addresses remain available as an explicit fallback for response-style UDP traffic.

IPv6 Extension Headers

Traverses IPv6 extension headers up to 6 levels deep to locate the transport protocol and prevent crafted-header bypass attacks. This logic now exists on both the XDP ingress path and the tc egress tracker, so IPv6 reply-state tracking is not limited to the simplest nexthdr cases. Non-initial IPv6 fragments are explicitly counted and dropped before the transport parser, so they cannot slip through on a failed bounds check.

Uninstall

# Detach XDP if it is attached
ip link set dev eth0 xdp off

# Remove the TCP/UDP reply tracker
tc filter del dev eth0 egress pref 49152 2>/dev/null || true

# Remove pinned maps and nftables fallback table
rm -rf /sys/fs/bpf/xdp_fw
nft delete table inet basic_xdp 2>/dev/null || true

# systemd
systemctl disable --now xdp-port-sync 2>/dev/null || true
rm /etc/systemd/system/xdp-port-sync.service
systemctl daemon-reload 2>/dev/null || true

# OpenRC
rc-service xdp-port-sync stop 2>/dev/null || true
rc-update del xdp-port-sync default 2>/dev/null || true
rm /etc/init.d/xdp-port-sync

# Remove installed runtime files
rm /usr/local/bin/xdp_port_sync.py
rm /usr/local/bin/bxdp
rm /usr/local/bin/basic_xdp_start.sh
rm -rf /usr/local/lib/basic_xdp
rm -rf /etc/basic_xdp

📊 Real-World Performance Benchmark

This benchmark simulates a volumetric UDP flood attack. We used a high-performance AMD EPYC™ 7Y43 server as the "Attacker" to stress-test a 1 vCPU AMD Ryzen 9 3900X instance protected by Basic XDP.

Test Environment

• 🇭🇰 Attacker: AMD EPYC™ 7Y43 @ 2.55GHz (Generating ~367k PPS / 188 Mbps)
• 🇺🇸 Target (Receiver): AMD Ryzen 9 3900X @ 2.0GHz (1 vCPU, 1GB RAM)
• Tool: pktgen (Linux Kernel Packet Generator)
• Attacker and target connected over public internet

Comparative Results

When XDP is off, the kernel networking stack processes every incoming packet, consuming nearly all CPU via soft interrupts. With XDP on, packets are dropped at the NIC driver level before reaching the stack — the same 367k PPS flood only uses 3% CPU, and the machine stays fully responsive.

XDP OFF — softirq at 85.9% under flood:

XDP ON — same flood, CPU drops to 3.0%:

XDP ON — before attack:

XDP ON — after attack:

How to reproduce

# Load the kernel module
modprobe pktgen

# Configure the device (replace enp3s0 with your interface name)
PGDEV=/proc/net/pktgen/INTERFACE

echo "rem_device_all" > /proc/net/pktgen/kpktgend_0
echo "add_device INTERFACE" > /proc/net/pktgen/kpktgend_0

# Set attack parameters
echo "count 10000000" > $PGDEV             # Send 10 million packets
echo "pkt_size 64" > $PGDEV                # Small packets put more stress on the CPU
echo "dst TARGET_IP" > $PGDEV         # Target IP
echo "dst_mac TARGET_MAC" > $PGDEV  # Target MAC
echo "clone_skb 100" > $PGDEV              # Speed up packet generation

🤝 Contributing

Contributions are welcome! If you have a bug fix, performance improvement, or new feature in mind:

1. Fork the repository
2. Create a feature branch (git checkout -b feature/my-improvement)
3. Commit your changes
4. Open a pull request For bugs or questions, please open an issue.

Star History

📄 License

MIT © 2026 Yunheng Liu
